CR 235GL

Total rated load：2.3tx1.0m
Maximum working radius：7.25m （180kg）
Maximum lifting height above ground： 7.3m
Output⁄Number of revolutions：6.6PS/1800rpm
Product description: Well-built outriggers made from thicker high tensile steel supports its compact body.
INQUIRY

Parameters：

Performance	Total rated load	2.3tx1.0m
	Maximum working radius	7.25m （180kg）
	Maximum lifting height above ground	7.3m
Boom	Length	7.5m
Boom	Number of sections	5
Engine	Output⁄Number of revolutions	6.6PS/1800rpm
Total weight		1570kg

Features：

STRONG & STABLE：Well-built outriggers made from thicker high tensile steel supports its compact body.

WHITE-COLORED CRAWLERS, LEAVING NO TRACKS：Equipped with white crawler shoes which enable you to drive without footwork on the floor.

TANDEM RUNNING SYSTEM：Capable to move smoothly over certain gap with its tandem system.

HYDRAULIC DRIVING MOTOR：Strong and easy to move. Capable of turnig on the spot.

OIL PRESSURE DRIVING LEVER：Capable to turning in a narrow space with simple lever operation.

LONGER BOOM：Stored auxiliary boom is available upon your needs for longer reach.

USER FRIENDLY FUEL TANK：simple design for both safety and easy maintenance.

PECIAL RADIO CONTROL DEVICE (OPTIONAL)：Specified low electric power radio control device, which enables you to operate from your convenience position.（Usage of this option is subjected to the related law of your country/region）

Download Catalogue（PDF）：download

PREVIOUS：CR 174G NEXT：CR 285D
